The heat shrinkable tube is made of high temperature resistant fluorine resin. The product has the advantages of high temperature resistance, flame retardant, resistance to external friction, corrosion resistance, high transparency, and can provide accurate inspection functions. It is suitable for shielding and grounding terminal processing, providing reliable protection and the embedded lead wire is convenient for installation. It is widely used in harsh fields such as communications, motors, and locomotive control systems.
Features
● Shrink rate:2:1
● Flame retardant
● High temperature resistance, corrosion resistance, external friction resistance, good sealing
● Clear heat shrink tubing provides precise viewing
● Operating temperature
● Initial shrink temperature:135℃
● Solder initial melting temperature:158℃
● Solder fully melting temperature:180℃
● Multi-Color hot melt adhesive.
Technical Data
| Product performance | Test Method | Standard |
| Tensile strength (Mpa) | ASTM D638 | ≥10.3 |
| Elongation(%) | ASTM D638 | ≥200 |
| Withstand voltage (V) | ASTM D149 | 2500V,60s,Pass |
| Breakdown strength(kV/mm) | ASTM D149 | ≥19.7 |
| Volume resistivity(Ω.cm) | IEC 93 | ≥1014 |
| Corrosion resistance | ASTM D2671 | Pass |
| Pulling forc | ASTM D2671 | ≥113N |
| Water absorption | ASTM D570 | ≤1.0 |
| art No | Heat Shrink Tubing(mm) | hot melt adhesive ring (mm) | solder ring (mm) | shielded wire (mm) | Standad Colors | |||
| I.D(φC) | I.D(φB) | Length(A) | Space(H) | I.D | A.W.G | Length | ||
| 150-3-55-18-90 | ≥3.00 | ≥2.50 | 40±0.5 | 12.00±0.5 | ≥2.50 | 18 | 165±5 | Red |
| 150-5-55-18-90 | ≥4.80 | ≥4.30 | 30±0.5 | 14.00±0.2 | ≥4.30 | 18 | 165±5 | Blue |
| 150-6-55-18-90 | ≥6.70 | ≥6.00 | 40±0.5 | 15.00±0.2 | ≥6.00 | 18 | 165±5 | Yellow |
| 150-7-55-18-90 | ≥7.30 | ≥6.40 | 31±0.5 | 16.00±0.2 | ≥6.40 | 18 | 165±5 | Blue |
| 150-9-55-18-90 | ≥9.20 | ≥8.70 | 36±0.5 | 17.00±0.2 | ≥8.70 | 18 | 165±5 | Blue |
| 150-11-55-18-90 | ≥11.50 | ≥10.00 | 34±0.5 | 18.00±0.2 | ≥10.00 | 18 | 165±5 | Blue |
| 150-13-55-18-90 | ≥15.00 | ≥13.00 | 47±0.5 | 18.00±0.2 | ≥13.00 | 18 | 165±5 | Blue |
